Horizon CL2 SN16 IJIS 16 Channel Snake Cable

Installer-Friendly!

Horizon Type CL2 16 Channel Snake Cable, Individually Jacketed, Individually Shielded, 24awg, Multipair Snake Wire. Available by the foot or on 500' or 1000' reels. Priced per foot.

Specifications



Cable: Conductor Gauge: Shield: Shield Coverage: Jacket: O.D. Capacitance: Cond.-Shield Capacitance: Characteristic Impedance: D.C. Resistance @ 20°C:

SN*-IJIS (*)24 gauge Alum/polyester tape and tinned copper drain 100% Matte PVC varies(see model number tab) 25 pF/ft. @ 1 kHz 45 pF/ft. @ 1 kHz 60Ω NOMINAL 24.5Ω/1000'

16 pair, 0.665" OD, lay length 8"

All bulk wire carries a full limited 1 year warranty to the original purchaser against defect in materials and workmanship. Items returned for warranty should be sent freight prepaid to our factory at the address listed below.

Please include proof of purchase, a brief description of the problem and your name and return shipping address. Qualifying items will be repaired or replaced at our discretion and shipped to the return address provided via normal ground service.

The RapcoHorizon Company
3581 Larch Lane
Jackson, MO 63755
