Sennheiser XSW 35 Wireless Hand-Held Microphone System

  • Sennheiser XSW 35 Wireless Hand-Held Microphone System
Brand: Sennheiser
Product Code: XSW 35
Availability: In Stock
Price: $399.95
Qty:     - OR -   Add to Wish List
Add to Compare

Sennheiser XSW 35 Wireless Hand-Held Microphone System

$399.95

General Description

Rugged, reliable and easy-to-use, XS Wireless delivers renowned Sennheiser sound to small venues, conference rooms or houses of worship. The XSW 35 Vocal Set with e835 cardioid dynamic capsule provides up to 10 hours of operation, a convenient mute button and excellent feedback rejection. An all-metal True Diversity receiver offers 960 tunable frequencies, with powerful scan and sync functions that ensure worry-free operation. Frequency range A (548-572 MHz)

Features
  • True Diversity reception for worry-free operation
  • 24 MHz switching bandwidth
  • 960 available frequencies, tunable in 25 kHz steps
  • 8 frequency banks containing 12 coordinated channels each
  • Powerful scan function identifies available channels within a bank
  • Component synchronization at a distance with new “Remote Channel” sync
  • Up to 10 hours of operation with (2) AA batteries
  • Up to 250 feet of transmission range
  • Illuminated audio mute button on transmitters
  • Balanced (XLR) and unbalanced (1/4”) outputs
  • 2 frequency ranges: A (548-572 MHz) and B (614-638 MHz)
Delivery Includes
  • (1) SKM35 Handheld Transmitter
  • (1) EM10 True Diversity Receiver
  • (1) NT 2-3 power supply
  • (1) MZQ1 mic clip
  • (2) rod antennas
  • (2) AA batteries
  • (1) Pouch
  • (1) Instruction manual
Technical Data
Modulation Wideband FM
Receiver principle True diversity
Sensitivity (at peak deviation) < 3 µV at 52 dBarms S/N
Frequency range A: 548-572 MHz, B: 614-638 MHz
Switching bandwidth 24 MHz
Adjacent channel rejection ≥ 60 dB
Intermodulation rejection ≥ 50 dB
Frequencies 960, tunable in 25 kHz steps
Frequency presets 8 frequency banks, each with 12 coordinated factory-preset channels
Blocking ≥ 65 dB
AF frequency response 60 Hz – 16 kHz
Signal-to-noise ratio ≥ 103 dBa
Total harmonic distortion (THD) ≤ 1%
Temperature range 32° F to 104° F (0° C to +40° C)
Antenna input 2 BNC connectors, 50 Ω
AF output voltage (at peak dev., 1 kHz AF) XLR (balanced): +14 dBu; ¼” (unbalanced): +8 dBu
Receiver power supply 12 VDC nom. / 300 mA
UPC code 615104219960
EAN code 4044155072860
Dimensions (single) 13.39 x 13.58 x 3.35 in

Weight (single)



Variants





XSW 35 Vocal Set - A   Model #504935 $399.95
A range = 548-572 MHz
XSW 35 Vocal Set - B   Model #504934 $399.95
B range = 614-638 MHz

3.99 lbs
