Primacoustic Broadway Control Columns 12" X 48"

Primacoustic Broadway Control Columns

12" X 48" X 1", 12 per box

12" X 48" X 2", 12 per box

12" X 48" X 3", 8 per box

• Used to control powerful primary reflections
• 'Roman Pillar' shape is ideal for spacing along walls
• Easy-to-install on practically any surface
• Adapts well to most architectural desings

Broadway Control Columns present an attractive, 'easy-to-install' solution for acoustic treatment where you want to control primary reflections, eliminate flutter echo and reduce standing waves.

Made from high density 6lb per cubic foot high density glass wool, Control Columns are designed to be arranged in a ‘spaced array’ to treat bothersome first order reflections that interact with the sound source and the listener. The panels are typically spread across a wall surface leaving space in between each panel. This allows some of the energy to reflect back into the room so as not to completely deaden the space while maximising the panel’s absorptive efficiency.

The Control Column's long narrow design is reminiscent of the historic 'Roman Pillar' making it an ideal compliment more demanding architectural designs. This makes the Control Columns an excellent choice for LEDE live-end / dead-end studio designs and home theatres. For those with creative flair, Control Columns can be combined with Primacoustic Accent panels to create an attractive solution for office spaces, board rooms, restaurants and lobbies that often need to be tamed in effort to reduce the reverberant field.

Broadway Control Columns come in a choice of 1", 2" and 3" thick panels with choice of square or bevelled edge. Color options include black, grey or beige.

Mounting

Mounting Control Columns is easy and quickly accomplished using Primacoustic Surface Impalers. Most installations only require two impalers per panel. For areas with higher traffic, three or four impalers may be used. For extra security, add a dab of construction adhesive on the impalers, to secure the panel in place. This is recommended in class rooms or public places.

Specifications

Core Material:	Formed, semi rigid inorganic glass fibers
Density:	6.0 lbs. per cubic foot (96 kg/m3)
Fabric Facing:	Acoustically transparent polyester tweed
Encapsulation:	Micromesh on front and rear surface, resin treated edges
Absorption H2O:	< 2% by weight @ 120°F (49°C), 95% relative humidity
Temperature:	-20°F ~ 150°F (-29°C ~ 66°C)
Fire Rating:	Class-A (ASTM E 84 / CAN/UL-S102 see details below)
Mounting:	Galvanized steel impalers
*Absorption Coefficient:		125	250	500	1000	2000	4000	NRC
	1"	0.17	0.28	0.81	1.00	1.02	0.95	0.71
	2"	0.45	0.83	1.07	1.00	1.01	1.00	0.89
	3"	0.92	0.91	1.00	1.00	1.02	1.03	0.98
Data Sheets & Test Reports:	Data Sheet		1" Lab Test		2" Lab Test		3" Lab Test

*Notice: In our opinion, the short form sound absorption coefficient does not provide reliable data regarding the performance of a particular panel versus the problem frequency. This data is provided for comparison sake only. Please view the full frequency chart below to ensure that the panel you are considering will actually attenuate the frequencies you are attempting to absorb.

Panel Details

Image	Size	Color	Order Number (xx denotes color code)	Thickness	Edge Treatment	Qty. in Box	Surface Coverage per Box
	12" x 48" (30.48 x 121.92 cm) Coverage: 4 sq-ft per panel (0.37 sq-meters)	Black=00 Beige=03 Grey=08	F101-1248-xx	1" (2.54cm)		12	48 sq-ft (4.46 sq-meters)
			F102-1248-xx	2" (5.08cm)		12	48 sq-ft (4.46 sq-meters)
			F122-1248-xx	2" (5.08cm)		12	48 sq-ft (4.46 sq-meters)
			F103-1248-xx	3" (7.62cm)		8	32 sq-ft (2.97 sq-meters)

Absorption Coefficients

1" (25mm) Broadway

2" (50mm) Broadway

3" (76mm) Broadway

Testing performed by Riverbank Acoustical Laboratories. The test method conformed explicitly with the requirements of the ASTM Standard Test Method for Sound Absorption and Sound Absorption Coefficients by the Reverberation Room Method: ASTM C 423-02a and E795-05.

Fire and Burn Performance for Broadway Panel Component

Test	Class	Flame Spread	Smoke Density	Test Data
ASTM E 84	1 or A	15	155
CAN/UL-S102	1 or A	15	155
Test data provided by Bodycote Materials Testing Inc. This method, designated as ASTM E 84-05, "Standard Method of Test for Surface Burning Characteristics of Building Materials", is used to measure and describe the response of materials, products, or assemblies to heat and flame under controlled conditions, but does not by itself incorporate all factors required for fire-hazard or fire-risk assessment under actual fire condition.
